The fully electronic SCPSi pressure switch is adjustable and free of vulnerable mechanical and moving components.
With its digital interface and smart functions, the SCPSi is designed to be future-proof for the increasing demands of automation solutions.The 2 switching outputs are parameterized individually and safely from the machine control via the standardized digital IO-Link interface (IEC 61131-9). This replaces manual programming and the commissioning phase is significantly reduced. A device replacement is possible during operation without re-parameterization. In order to react promptly to machine status changes or process adjustments, the reparameterization takes place during operation.
Device characteristics:
• Pressure switch / sensor
• Temperature measurement
• Industry 4.0 ready
• IO-Link 1.1
• Smart Sensor Profile 2nd edition
• Plug & Play
• Compact
• Optimized design
• Adjustable via IO-Link
• Readable via IO-Link
• Can be used as an IO-Link sensor or switch
• Monolithic pressure cell
| Protection: | IP 67 |
| Precision: | ≤ 0,5 %FS |
| Weight in kg: | 0,12 |
| Connection: | Male thread 1/4" |
| RoHS compliant: | Yes |
| Load change: | ≥ 100 Mio. |
| Power supply: | 18...30 VDC |
| Material: | Stainless steel |
| Pressure measurement range: | -1 - 25 bar |
| Working temperature: | -25°C to +85°C |
| Electrical connection: | Circular connector M12x1; 4 pin |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
