The SCP03 is a pressure sensor for liquid and gaseous media.
The digitally adjusted piezoresistive measuring cell records negative pressures from -1 bar up to high pressures of 1000 bar.The pressure connection that comes into contact with the medium has a monolithic structure. This eliminates internal seals and welds. A mix of materials is avoided.
The resulting low permeability in combination with the stainless steel result in a wide range of media resistance.
Device characteristics:
• Monolithic design
· No internal seal
· No mix of materials
· No weld
• High media compatibility
• Measuring range from -1 to 1000 bar
• Resistant to vacuum
• Lots of connections
| Precision: | ± 0.3 % FS |
| Weight in kg: | 0,08 |
| Connection: | Male thread 1/4" |
| RoHS compliant: | Yes |
| Load change: | ≥ 100 Mio. |
| Material: | Stainless steel |
| Pressure measurement range: | 0 - 10 bar |
| Working temperature: | -40°C to +105°C |
| Electrical connection: | Circular connector M12x1; 4 pin |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
