Product information "MD Drive Frequency converter for BME 40-6500 WS | BME 40-6500 B"
The MD Drive frequency converter is precisely matched to Mannesmann Demag's electric drives. Its compact metal housing saves space and can be mounted in the control cabinet. This also allows the spindle itself to have a very compact design.
Weight in kg:
0,5
Drive:
Electrical
Item number:
60076045
Output frequency:
S1: 1.667 Hz, max. 100.000 min^-1
Output current:
S1: 13 A, max. 18 A - 60s
Brake resistor:
Integrated
EMC:
EN 61800-3
Form:
Cabinet version
Internal memory:
2 Motor parameters
Type of motor:
3 ~ selsyn motor (PMSM)
Rated output power:
S1: 660 W, max. 880 W
Protection:
IP 10 / Class III according to DIN EN 61800-5-1
Voltage:
Logic supply: 24 V DC (0,5 A), Output voltage: 33 V AC
Power supply:
48 V DC
Working temperature:
10°C to 40°C
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
