• Designed to transport water and liquids
• High flow capability
• Maximum energy efficiency
Series: | Medium |
Flow rate in l/min: | 2.200 (air) |
Material connection: | Brass nickel plated |
Series long: | Medium |
Working temperature: | -20°C up to +100°C (NBR) |
Surface: | nickel plated |
Shut-Off: | Plug Straight-Through |
Connection: | Plug |
Connection description: | Quick coupling manifold |
Connection type: | Other connections |
Bore in mm: | 12 |
Maximum working pressure in bar: | 20 |
Material seal: | NBR |
Material: | Brass nickel plated |
RoHS compliant: | Yes |
Weight in kg: | 0,132 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
