Series: | 1800 |
Old order number: | 18110 |
Series long: | 1800SF |
Bore area in mm²: | 80 |
Advantages: | High flow. Single handed operation. Compact build. |
Compatibility: | Rectus 32 |
Working pressure: | 35 bar maximum static working pressure with safety factor 4 to 1. |
Working temperature: | -20°C up to +100°C (NBR) -40°C up to +120/150°C (EPDM) -15°C up to +200°C (FKM) depending on the medium. |
Shut-Off: | Plug Straight-Through |
Connection: | Male thread G 1/4 |
Connection description: | Male thread G 1/4 |
Material: | Steel, zinc-plated |
Material description: | Steel 9SMnPb28K 1.0718 |
Surface: | zinc plated |
Weight in kg: | 0,029 |
Self-venting coupling: | No |
Safety locking system: | No |
Single-hand operation: | Yes |
Two-hand operation: | No |
Ultra-FLO-valve: | Yes |
Water-resistant: | No |
Flat-sealing: | No |
Suitable breath / respiratory protection: | No |
Pressure eliminator: | No |
Hydraulics: | No |
Pneumatics: | Yes |
Mould coupling: | No |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
