MUD 82-100 Air motor

Air motor, reversible, speed under load 100 rpm, torque 78 Nm, start torque 117 Nm

Price on request

Available, delivery time:

Product information "MUD 82-100 Air motor"

The robustness distinguishes the air motor as unproblematic drive engine. It is well utilised in industrial sectors where accuracy and longevity are required. Its high starting torque and the wide torque range qualifies it for many needs in the drive section. Reversible motors can be used rotating clockwise and anti clockwise. It is very important that if the air motor is pressurized with connection turning the air motor left, the connection turning the air motor right is vented properly (and vize versa). All data related to 6.3 bar working pressure.

Resistant to stalling:	Yes
Item number:	60002437
ATEX available:	Yes
Brake:	No
Torque in Nm:	78
Maximum torque in Nm:	156
Direction of rotation:	Reversible
Weight in kg:	4,6
Torque in Nm:	78
Speed under load in rpm:	100
Idling speed rpm:	200
Power in kW:	0,82
Air consumption in l/s:	18
Material:	Stainless steel
Non-lubricated:	Yes
Start torque in Nm:	117
Shaft load Fa max. in N:	2800
Shaft load Fr max. in N:	5600

All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
