Oil trap
Product information "Oil trap"
- Exhaust air is collected centrally
- Unoiled compressed air streams into the environment (filtering up to 99%)
- Residual oil content at the outlet at max. 900 l/min: 0.01 mg/m³
- The pressure dew point must be at least 15°C below the ambient and medium temperature and must not exceed 3°C
- The oil content of the compressed air must remain constant throughout its entire service life
• 2 threaded connections G 3/4"
• max. operating pressure 16 bar
• nominal flow Qn 12000 L/min
• temperature range - 20 °C until + 120 °C
• weight 0,58 kg
| Connection: | Female thread 3/4" |
|---|---|
| Weight in kg: | 0,58 |
| Maximum working pressure in bar: | 16 |
| Working temperature: | -20°C up to +120°C |
| Item number: | 60070826 |
| SW mm: | 41 |
|---|
