Air motors 0,50 kW

Air motors, reversible, speed under load 14 - 9.500 rpm, torque 0,5 - 341,0 Nm, start torque 0,75 - 512,0 Nm

Price on request

Available, delivery time:

Product name	Idling speed rpm	Torque in Nm	Speed under load in rpm	Non-lubricated	Start torque in Nm
MUD 40-14 Air motor	28	341	14	No	512
MUD 40-20 Air motor	40	238	20	No	357
MUD 40-40 Air motor	80	119	40	No	179
MUD 40-65 Air motor	130	73	65	No	110
MUD 40-90 Air motor	180	53	90	No	80
MUD 40-220 Air motor	440	22	220	No	33
MUD 40-265 Air motor	530	18	265	No	27
MUD 40-355 Air motor	710	13	355	No	20
MUD 40-430 Air motor	860	11	430	No	17
MUD 40-575 Air motor	1150	8,3	575	No	12
MUD 40-1500 Air motor	3000	3,2	1500	No	4,8
MUD 40-1700 Air motor	3400	2,8	1700	No	4,2
MUD 40-2400 Air motor	4800	2	2400	No	3
MUD 40-9500 Air motor	19000	0,5	9500	No	0,75
MUD 40-220 F77 Air motor	440	22	220	No	33
MUD 40-265 F77 Air motor	530	18	265	No	27
MUD 40-355 F77 Air motor	710	13	355	No	20
MUD 40-575 F77 Air motor	1150	8,3	575	No	12
MUD 40-1500 F77 Air motor	3000	3,2	1500	No	4,8
MUD 40-1700 F77 Air motor	3400	2,8	1700	No	4,2
MUD 40-2400 F77 Air motor	4800	2	2400	No	3
MUD 40-9500 F77 Air motor	19000	0,5	9500	No	0,75
MUD 40-40 F100 Air motor	80	119	40	No	179
MUD 40-65 F100 Air motor	130	73	65	No	110
MUD 40-90 F100 Air motor	180	53	90	No	80

Product information "Air motors 0,50 kW"

The robustness distinguishes the air motor as unproblematic drive engine. It is well utilised in industrial sectors where accuracy and longevity are required. Its high starting torque and the wide torque range qualifies it for many needs in the drive section. Reversible motors can be used rotating clockwise and anti clockwise. It is very important that if the air motor is pressurized with connection turning the air motor left, the connection turning the air motor right is vented properly (and vize versa).
