Air motors, rotating clockwise, speed under load 25 - 10.500 rpm, torque 0,59 - 233,0 Nm, start torque 0,89 - 349,0 Nm

Product name	Speed under load in rpm	Torque in Nm	Start torque in Nm	Idling speed rpm	Non-lubricated	Torque in Nm
MRD 65-25 Air motor	25	233	349	50	Yes	233
MRD 65-35 Air motor	35	166	249	70	Yes	166
MRD 65-60 Air motor	60	98	148	120	Yes	98
MRD 65-85 Air motor	85	70	104	140	Yes	70
MRD 65-145 Air motor	145	40	60	290	Yes	40
MRD 65-290 Air motor	290	21	31	580	Yes	21
MRD 65-500 Air motor	500	12	18	1000	Yes	12
MRD 65-650 Air motor	650	9,4	14	1300	Yes	9,4
MRD 65-1300 Air motor	1300	4,7	7	2600	Yes	4,7
MRD 65-2300 Air motor	2300	2,7	4	4600	Yes	2,7
MRD 65-10500 Air motor	10500	0,59	0,89	21000	Yes	0,59
MRD 65-290 F80 Air motor	290	21	31	580	Yes	21
MRD 65-650 F80 Air motor	650	9,4	14	1300	Yes	9,4
MRD 65-1300 F80 Air motor	1300	4,7	7	2600	Yes	4,7
MRD 65-2300 F80 Air motor	2300	2,7	4	4600	Yes	2,7
MRD 65-2900 F80 Air motor	2900	2,1	3,2	5800	Yes	2,1
MRD 65-10500 F80 Air motor	10500	0,59	0,89	21000	Yes	0,59
MRD 65-60 F100 Air motor	60	98	148	120	Yes	98
MRD 65-85 F100 Air motor	85	70	104	140	Yes	70
MRD 65-145 F100 Air motor	145	40	60	290	Yes	40

The robustness distinguishes the air motor as unproblematic drive engine. It is well utilised in... more

Close menu

Product information "Air motors 0,65 kW"

The robustness distinguishes the air motor as unproblematic drive engine. It is well utilised in industrial sectors where accuracy and longevity are required. Its high starting torque and the wide torque range qualifies it for many needs in the drive section.
