The robustness distinguishes the air motor as unproblematic drive engine. It is well utilised in industrial sectors where accuracy and longevity are required. Its high starting torque and the wide torque range qualifies it for many needs in the drive section. All data related to 6.3 bar working pressure.
Resistant to stalling:
Yes
Item number:
60024667
ATEX available:
Yes
Brake:
No
Torque in Nm:
233
Maximum torque in Nm:
466
Direction of rotation:
Rotating clockwise
Weight in kg:
5,4
Torque in Nm:
233
Speed under load in rpm:
25
Idling speed rpm:
50
Power in kW:
0,61
Air consumption in l/s:
13
Material:
Stainless steel
Non-lubricated:
Yes
Start torque in Nm:
349
Shaft load Fa max. in N:
2800
Shaft load Fr max. in N:
5600
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
