Series: | T |
Valve: | with |
Seal: | FKM |
Series long: | 7500 |
Bore in mm: | 20 |
Bore area in mm²: | 314 |
Size in general: | 3/4" |
Advantages: | High operating pressure. Compact dimension. Due to the Pressure Eliminator version for coupling and plug the connection is possible up to the operating pressure. Double safety through a double O-ring seal. A safety closing ring prevents unintentional uncoupling. |
Coupled working pressure in bar: | 280 |
Working temperature: | -30°C up to +100°C (NBR) -25°C up to +200°C (FKM) depending on the medium. |
Shut-Off: | Quick coupling Double Shut-Off |
Connection: | Female thread 3/4" |
Connection type: | Female thread |
Material: | Brass |
Surface: | nickel plated and chrome plated |
Material valve body: | Brass |
Material sleeve: | Steel hardened, zinc-plated, passivated, sealed |
Material locking collar: | Messing, Zink-Eisen beschichtet, schwarz passiviert, versiegelt |
Material valve: | Brass |
Material valve holder: | Brass |
Material spring snap ring: | 1.4310 |
Material balls/pins: | 1.3541 |
Weight in kg: | 0,5871 |
Safety locking system: | Yes |
Single-hand operation: | Yes |
Two-hand operation: | No |
Ball locking: | Yes |
Vacuum suitable: | No |
Flat-sealing: | No |
Pressure eliminator: | No |
Hydraulics: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
