Series: | 30 |
Seal: | NBR |
Series long: | 30KA |
Bore in mm: | 8,5 |
Bore area in mm²: | 60 |
Advantages: | Very robust design with steel valve body. |
Compatibility: | INDUSTRIAL INTERCHANGE 3/8" US-MIL-SPEC-C-4109 ISO 6150 B PARKER 30 3/8" |
Working pressure: | 35 bar maximum static working pressure with safety factor 4 to 1. |
Working temperature: | -20°C up to +100°C (NBR) -40°C up to +120/150°C (EPDM) -15°C up to +200°C (FKM) depending on the medium. |
Shut-Off: | Quick coupling Single Shut-Off |
Connection: | Male thread NPT 3/8" |
Connection description: | Male NPT thread ANSI B 1.20.1 conical 3/8" |
Connection type: | Male thread |
Material: | Steel |
Material description: | Steel 9SMnPb28K 1.0718 |
Seal description: | Nitrite-butadiene rubber |
Surface: | blank finish |
Material connection: | Brass |
Material valve body: | steel, yellow zinc plated |
Material sleeve: | Brass |
Material valve: | Brass |
Material spring snap ring: | stainless steel AISI 301 |
Material balls/pins: | Stainless steel AISI 420 |
Material seal: | Perbunan® |
Weight in kg: | 0,1231 |
Self-venting coupling: | No |
Safety locking system: | No |
Single-hand operation: | Yes |
Two-hand operation: | No |
Ball locking: | No |
Pin lock: | Yes |
Ultra-FLO-valve: | No |
Vacuum suitable: | Yes |
Water-resistant: | No |
Flat-sealing: | No |
Suitable breath / respiratory protection: | No |
Pressure eliminator: | No |
Hydraulics: | No |
Pneumatics: | Yes |
Standard product: | No |
Mould coupling: | No |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
