Series: | 26 |
Seal: | EPDM |
Series long: | 26KA |
Bore in mm: | 7,2 |
Bore area in mm²: | 40 |
Advantages: | One-hand operation. European standard. |
Compatibility: | RECTUS 25 RECTUS 1600/1625 TEMA 1600 |
Working pressure: | 35 bar maximum static working pressure with safety factor 4 to 1. |
Working temperature: | -20°C up to +100°C (NBR) -40°C up to +120/150°C (EPDM) -15°C up to +200°C (FKM) depending on the medium. |
Shut-Off: | Quick coupling Single Shut-Off |
Connection: | Male thread 3/8" |
Connection description: | Male pipe thread of Whitworth form ISO 228 3/8" |
Connection type: | Male thread |
Material: | Brass |
Material description: | Brass CuZn39Pb3 2.0401 (except sleeve) |
Seal description: | Ethylene-propylene-diene rubber |
Surface: | blank finish |
Material connection: | Brass |
Material valve body: | Brass |
Material sleeve: | Brass |
Material valve: | Brass |
Material spring snap ring: | stainless steel AISI 301 |
Material balls/pins: | Stainless steel AISI 420 |
Weight in kg: | 0,0752 |
Self-venting coupling: | No |
Safety locking system: | No |
Single-hand operation: | Yes |
Two-hand operation: | No |
Ball locking: | No |
Pin lock: | Yes |
Ultra-FLO-valve: | No |
Vacuum suitable: | Yes |
Water-resistant: | Yes |
Flat-sealing: | No |
Suitable breath / respiratory protection: | No |
Pressure eliminator: | No |
Hydraulics: | No |
Pneumatics: | Yes |
Standard product: | Yes |
Mould coupling: | No |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
