Series: | 25 |
Seal: | Without Seal |
Series long: | 25SF |
Bore in mm: | 7,8 |
Bore area in mm²: | 48 |
Advantages: | One-hand operation. Robust structure. UltraFlo valve. |
Compatibility: | RECTUS 26 European standard profiles |
Working pressure: | 35 bar maximum static working pressure with safety factor 4 to 1. |
Working temperature: | -20°C up to +100°C (NBR) -40°C up to +120/150°C (EPDM) -15°C up to +200°C (FKM) depending on the medium. |
Shut-Off: | Plug Straight-Through |
Connection: | Male thread 1/4" |
Connection description: | Male pipe thread of Whitworth form ISO 228 1/4" |
Connection type: | Male thread |
Material: | stainless steel AISI 316 L |
Material description: | stainless steel 1.4404 |
Surface: | blank finish |
Weight in kg: | 0,018 |
Self-venting coupling: | No |
Safety locking system: | No |
Single-hand operation: | Yes |
Two-hand operation: | No |
Ball locking: | No |
Pin lock: | No |
Ultra-FLO-valve: | No |
Vacuum suitable: | No |
Water-resistant: | No |
Flat-sealing: | No |
Suitable breath / respiratory protection: | No |
Pressure eliminator: | No |
Hydraulics: | No |
Pneumatics: | Yes |
Standard product: | No |
Mould coupling: | No |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
