• Designed to transport water and liquids
• Very high flow rate
• Ideal for water applications
Series: | Maxi |
Flow rate in l/min: | 8.500 (air) |
Material connection: | Brass nickel plated |
Series long: | Maxi |
Working temperature: | -20°C up to +100°C (NBR) |
Surface: | nickel plated |
Shut-Off: | Plug Straight-Through |
Connection: | Male thread G 3/4 |
Connection description: | BSPP |
Connection type: | Male thread |
Bore in mm: | 19 |
Maximum working pressure in bar: | 20 |
Material: | Brass nickel plated |
RoHS compliant: | Yes |
Weight in kg: | 0,09 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
