Series: | 21 |
Seal: | Without Seal |
Series long: | 21SF |
Bore in mm: | 5 |
Bore area in mm²: | 20 |
Advantages: | Quality product. One-hand operation. |
Working pressure: | 35 bar maximum static working pressure with safety factor 4 to 1. |
Working temperature: | -20°C up to +100°C (NBR) |
Shut-Off: | Plug Straight-Through |
Connection: | Hose barb 8mm LW(5/16") |
Connection description: | Hose barb 8mm LW(5/16") |
Connection type: | Hose barb |
Material: | Brass |
Material description: | Brass CuZn39Pb3 2.0401 (except sleeve) |
Surface: | blank finish |
Coding: | 0 = green, circle |
Weight in kg: | 0,0221 |
Coded: | Yes |
Self-venting coupling: | No |
Safety locking system: | No |
Single-hand operation: | Yes |
Two-hand operation: | No |
Ball locking: | No |
Pin lock: | No |
Ultra-FLO-valve: | No |
Vacuum suitable: | Yes |
Water-resistant: | Yes |
Flat-sealing: | No |
Suitable breath / respiratory protection: | No |
Pressure eliminator: | No |
Hydraulics: | No |
Pneumatics: | Yes |
Standard product: | No |
Mould coupling: | No |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
