Series: | 20 |
Seal: | FKM/FPM |
Series long: | 20KA |
Bore in mm: | 2,7 |
Bore area in mm²: | 6 |
Advantages: | One-hand operation. Small dimensions. |
Compatibility: | RECTUS 91 |
Working pressure: | 35 bar maximum static working pressure with safety factor 4 to 1. |
Working temperature: | -20°C up to +100°C (NBR) -40°C up to +120/150°C (EPDM) -15°C up to +200°C (FKM) depending on the medium. |
Shut-Off: | Quick coupling Single Shut-Off |
Connection: | Female thread 1/8" |
Connection description: | Female pipe thread of Whitworth form ISO 228 1/8" |
Connection type: | Female thread |
Material: | stainless steel AISI 316 L |
Material description: | stainless steel 1.4404 |
Seal description: | Fluororubber |
Surface: | blank finish |
Material connection: | stainless steel AISI 316 L |
Material valve body: | stainless steel AISI 316 L |
Material sleeve: | stainless steel AISI 316 L |
Material valve: | stainless steel AISI 316 L |
Material spring snap ring: | Stainless steel AISI 316Ti |
Material balls/pins: | Stainless steel AISI 316 |
Material seal: | Viton® |
Weight in kg: | 0,014 |
Self-venting coupling: | No |
Safety locking system: | No |
Single-hand operation: | Yes |
Two-hand operation: | No |
Ball locking: | Yes |
Pin lock: | No |
Ultra-FLO-valve: | No |
Vacuum suitable: | Yes |
Water-resistant: | No |
Flat-sealing: | No |
Suitable breath / respiratory protection: | No |
Pressure eliminator: | No |
Hydraulics: | No |
Pneumatics: | Yes |
Standard product: | No |
Mould coupling: | No |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
