Can be used in hydraulic systems where rotating connections are essential, for example on accessories with rotating movements. Depending on design, the body is made of brass (DG) or steel (KR) and the rotating axis of surfacepurified/stainless steel. Maximum rotation speed: 60 r.p.m.
| Series: | KR |
| Seal: | NBR |
| Series long: | KR |
| Maximum working pressure in bar: | 250 |
| Advantages: | Rotating joints minimise the high wear to the hose, which occurs in hydraulic systems. Solid construction with two plain bearings (DG) or ball/ roller bearings (KR). Suitable for combining with norm hydraulic components. |
| Additional information: | only suitable for oil |
| Working temperature: | -40°C up to +90°C (NBR) depending on the medium. |
| Connection type: | Female / Male thread |
| Material body: | Steel, zinc-plated, passivated, sealed |
| Material counterpart: | Steel, zinc-plated, passivated, sealed |
| Material axis of rotation: | Steel hardened, zinc-plated, passivated, sealed |
| Material nut/adapter: | Steel, zinc-plated, passivated, sealed |
| Weight in kg: | 1,0567 |
| Hydraulics: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
