Series: | 10 |
Seal: | FKM |
Series long: | 10KF |
Bore in mm: | 6 |
Bore area in mm²: | 30 |
Advantages: | Available in single shut-off, double shut-off or straightthrough versions also available with SAFE-LOCK™-technology. The straight-through couplingsare equipped with nickel plated sleeves for quick and accurate visual differentiation. The angular connections prevent kinks from forming in the hose. |
Working pressure: | PB = 15 bar maximum static working pressure with safety factor 4 to 1. |
Working temperature: | -15°C up to +200°C (FKM) depending on the medium |
Shut-Off: | Quick coupling Straight-Through |
Connection: | Hose barb 9mm LW(3/8") |
Connection description: | Hose barb 9mm LW(3/8") |
Connection type: | Hose barb |
Material: | Brass |
Material description: | Brass CuZn39Pb3 2.0401 (except sleeve) |
Seal description: | Fluororubber |
Surface: | blank finish |
Material connection: | Brass |
Material valve body: | Brass |
Material sleeve: | Brass |
Material spring snap ring: | stainless steel AISI 301 |
Material balls/pins: | Stainless steel AISI 420 |
Material seal: | Viton® |
Weight in kg: | 0,0536 |
Self-venting coupling: | No |
Safety locking system: | No |
Single-hand operation: | Yes |
Two-hand operation: | No |
Ball locking: | Yes |
Pin lock: | No |
Ultra-FLO-valve: | No |
Vacuum suitable: | Yes |
Water-resistant: | Yes |
Flat-sealing: | No |
Suitable breath / respiratory protection: | No |
Pressure eliminator: | No |
Hydraulics: | No |
Pneumatics: | No |
Standard product: | No |
Mould coupling: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
