The in-line progressive starter is a valve that regulates the flow of air until the outlet pressure reaches a certain value, at which the valve opens and allows air to flow at full rate.
This valve can be used to control a group of valves or a single valve, or it can be mounted between another valve and an actuator.
The air that enters inlet 1 passes through a choke that has a knob adjustment to control the flow. The valve opens completely when the outlet pressure reaches about 60% of the inlet pressure.
If the air supply is switched off, the valve discharges air from outlet 2 to inlet 1.
This valve can be used to control a group of valves or a single valve, or it can be mounted between another valve and an actuator.
The air that enters inlet 1 passes through a choke that has a knob adjustment to control the flow. The valve opens completely when the outlet pressure reaches about 60% of the inlet pressure.
If the air supply is switched off, the valve discharges air from outlet 2 to inlet 1.
| Flow rate in l/min: | 3100 Nl/min (at 6.3 bar, ?P=1 bar) |
| Medium suitability: | Filtered, lubricated or unlubricated, compressed air. Lubrication, if used, must be continuous. |
| Connection: | Female thread 1/2" |
| Switching pressure: | About 60% of inlet pressure |
| max. operating frequency: | 5 Hz |
| Working temperature: | -10 – +70 °C |
| Screw size: | Min. M4x35 |
| Mounting position: | In any position |
| Maximum working pressure in bar: | 2 bar |
| Maximum working pressure in bar: | 10 bar |
| Flow rate through flow regulator: | max. 300 Nl/min (at 6.3 bar) |
| Function: | 2/2 NC |
| Material body: | Anodized aluminium |
| Weight in kg: | 0,22 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
