Industrial hose balancer with automatic withdrawal of the hose. The inner diameter of the hose (10 mm) ensures appropriate air supply for larger tools. A rachet mechanism can be activated separately for positioning the tool in any desired height. A safety lock prevents the hanged tool from falling if the spring breaks. Extension hoses for work in great heights are optionally available. connection R 3/8"” to air supply and R 3/8"” on the tool.
| Series: | ATR |
| Series long: | ATR |
| Payload range in kg: | 3,5 - 5 |
| Cable length in m: | 2 |
| Material casing: | Plastic |
| Suspension: | Turnable carabiner |
| Load setting: | External hexagon |
| Cable stop: | Yes, adjustable |
| Locking: | Yes |
| Connection (casing): | Female thread R 3/8" |
| Connection (hose): | Female thread R 3/8" |
| Maximum working pressure in bar: | 8 |
| Spring fracture protection: | Yes |
| Fall protection: | Preparation existing |
| Weight in kg: | 3,8 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
