Highly reliable, heavy-duty piston-operated regulator.
Adjusted pressure stays constant despite pressure variations.
Standard overpressure blowoff valve.
Direct wall fixing or with distance.
Including pressure gauge.
Adjusted pressure stays constant despite pressure variations.
Standard overpressure blowoff valve.
Direct wall fixing or with distance.
Including pressure gauge.
| Series: | Newdeal |
| Connection: | Female thread G 1/4" |
| max. inlet pressure: | 18 |
| Flow rate in l/min: | 200 |
| Seals: | NBR |
| Dome: | Technopolymer |
| Adjustment spring: | Steel |
| Adjustment knob: | Technopolymer |
| Adjusting screw: | Brass Ms58 |
| Body: | Zamac |
| Piston: | Technopolymer |
| Lip seal: | NBR |
| Nut: | Brass Ms58 |
| Ring nut: | Technopolymer |
| Bar: | Brass Ms58 |
| Plug: | Technopolymer |
| Valve spring: | Steel |
| Valve part: | Vulcanized with NBR |
| Weight in kg: | 0,324 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
