• Quantity of lubricant proportioned to air flow.
• Activates at low flow rates.
• Micrometric regulation of lubricant flow.
• All-round oil level viewing.
Series: | Bit |
Connection: | Female thread G 1/4" |
max. inlet pressure: | 13 |
Mounting position: | Vertical |
Installation: | M4 by means of the bracket provided |
Type of oiling: | Drip lubricator |
Flow rate in l/min: | 710 |
Transparent container: | Transparent technopolymer |
Body: | Technopolymer with threaded sleeve brass Ms58 |
Oiler dome: | Transparent technopolymer |
Control needle: | Brass Ms58 |
Hose: | Rilsan® |
Plug: | Technopolymer |
Venturi system: | NBR |
Weight in kg: | 0,04 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
