Air motors 0,62 kW

To be able to use maku Industrie GmbH & Co. KG in full range, we recommend activating Javascript in your browser.

Air motors, reversible, speed under load 20 - 8.600 rpm, torque 0,7 - 277,0 Nm, start torque 1,0 - 416,0 Nm

Product name	Speed under load in rpm	Torque in Nm	Start torque in Nm	Idling speed rpm	Non-lubricated	Torque in Nm
MUD 62-20 Air motor	20	277	416	40	Yes	277
MUD 62-28 Air motor	28	197	296	56	Yes	197
MUD 62-50 Air motor	50	114	171	100	Yes	114
MUD 62-70 Air motor	70	81	122	140	Yes	81
MUD 62-120 Air motor	120	47	71	240	Yes	47
MUD 62-230 Air motor	230	25	37	460	Yes	25
MUD 62-370 Air motor	370	16	23	740	Yes	16
MUD 62-525 Air motor	525	11	16	1050	Yes	11
MUD 62-1000 Air motor	1000	5,9	8,8	2000	Yes	5,9
MUD 62-1890 Air motor	1890	3,1	4,6	3780	Yes	3,1
MUD 62-2400 Air motor	2400	2,4	3,7	4800	Yes	2,4
MUD 62-8600 Air motor	8600	0,7	1	17200	Yes	0,7
MUD 62-230 F80 Air motor	230	25	37	460	Yes	25
MUD 62-370 F80 Air motor	370	16	23	740	Yes	16
MUD 62-525 F80 Air motor	525	11	16	1050	Yes	11
MUD 62-1000 F80 Air motor	1000	5,9	8,8	2000	Yes	5,9
MUD 62-2400 F80 Air motor	2400	2,4	3,7	4800	Yes	2,4
MUD 62-8600 F80 Air motor	8600	0,7	1	17200	Yes	0,7
MUD 62-50 F100 Air motor	50	114	171	100	Yes	114
MUD 62-70 F100 Air motor	70	81	122	140	Yes	81
MUD 62-120 F100 Air motor	120	47	71	240	Yes	47

The robustness distinguishes the air motor as unproblematic drive engine. It is well utilised in... more

Close menu

Product information "Air motors 0,62 kW"

The robustness distinguishes the air motor as unproblematic drive engine. It is well utilised in industrial sectors where accuracy and longevity are required. Its high starting torque and the wide torque range qualifies it for many needs in the drive section.
Reversible motors can be used rotating clockwise and anti clockwise. It is very important that if the air motor is pressurized with connection turning the air motor left, the connection turning the air motor right is vented properly (and vize versa).
