The robustness distinguishes the air motor as unproblematic drive engine. It is well utilised in industrial sectors where accuracy and longevity are required. Its high starting torque and the wide torque range qualifies it for many needs in the drive section. The robust teethed gears of the motors from 2,2 to 4,4 kW ensure the necessary reduction for the required speed under load.
Resistant to stalling:
Yes
Item number:
29942555
ATEX available:
Yes
Brake:
Yes
Torque in Nm:
563
Maximum torque in Nm:
1126
Direction of rotation:
Reversible
Weight in kg:
25
Holding load of brake:
732
Torque in Nm:
563
Speed under load in rpm:
75
Idling speed rpm:
150
Power in kW:
4,4
Air consumption in l/s:
83
Material:
Stainless steel
Non-lubricated:
No
Start torque in Nm:
845
Shaft load Fa max. in N:
2300
Shaft load Fr max. in N:
3500
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
