The Timer is part of Metal Work range of logic elements, which also includes OR, AND, NOT, YES, MEMORY. The value of the signal output delay is set by rotating a knob. It can work both as 3/2 NC and 3/2 NO, depending on whether feeding is through port “a“ or port “b”.
The maximum delay time can be increased by unscrewing a plug and connecting the port to an external auxiliary tank.
• Adaptor for ? bar (DIN EN 50022) integrated in the body.
• Pressure indicator via an orange pin
• Pipe clamping system using Ø 4 built-in push-on fittings.
The maximum delay time can be increased by unscrewing a plug and connecting the port to an external auxiliary tank.
• Adaptor for ? bar (DIN EN 50022) integrated in the body.
• Pressure indicator via an orange pin
• Pipe clamping system using Ø 4 built-in push-on fittings.
| Flow rate in l/min: | 100 (at 6 bar) |
| Medium suitability: | Filtered, lubricated or unlubricated compressed air. If used, must be continuous. |
| Connection: | Push-in fitting 4 mm outside calibrated |
| Installation: | An Omegaschiene (DIN EN 50022) Größe 35 x 7 oder 35 x 15 Wandmontage mit Löchern Ø 4.2 |
| Mounting position: | In any position |
| Actuation: | Pneumatic |
| Resetting: | spring operated |
| Working pressure: | 2,5 – 8 bar |
| Material spring: | Spring steel |
| Material seal: | NBR |
| Material body: | Anodized aluminium / Technopolymer |
| Weight in kg: | 0,3 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
