Circuit selector valves - OR VOR 1/4

Logic element OR, logic sum, 2 inputs 1 output, 2-10 bar, 1/4" female thread

€17.23

Available in 10 days, transport time 1-2 working days

Product information "Circuit selector valves - OR VOR 1/4"

Circuit selector valves select two separate input signal without creating reciprocal interference, giving a single output signal.

Shutdown time:	< 0,1s
Connection:	Female thread 1/4"
Working pressure:	2 – 10 bar
Flow rate in l/min:	1300 (at 6,3 bar)
Weight in kg:	0,3
Medium suitability:	Filtered, lubricated or unlubricated compressed air. If used, must be continuous.
Material seal:	NBR
Material body:	Aluminium
Repeatability:	± 0,4s
Time setting range:	0 – 30s

All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
