Metal Work logic elements are available with 5 different functions: OR, AND, NOT, YES, MEMORY.
Main features common to all elements:
• Adaptor for ? bar (DIN EN 50022) integral with the body.
• Built-in pressure indicator.
• Pipe locking system using Ø 4 built-in fittings.
Main features common to all elements:
• Adaptor for ? bar (DIN EN 50022) integral with the body.
• Built-in pressure indicator.
• Pipe locking system using Ø 4 built-in fittings.
| Flow rate in l/min: | 100 (at 6 bar) |
| Medium suitability: | Filtered, lubricated or unlubricated compressed air. If used, must be continuous. |
| Connection: | Push-in fitting 4 mm outside calibrated |
| Installation: | An Omegaschiene (DIN EN 50022) Größe 35 x 7 oder 35 x 15 Wandmontage mit Löchern Ø 4.2 |
| Mounting position: | In any position |
| Actuation: | Pneumatic |
| Resetting: | spring operated |
| Working pressure: | 0 – 8 bar |
| Material seal: | NBR |
| Material body: | Technopolymer |
| #NV: | Aluminium |
| Weight in kg: | 0,3 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
