Robust filter regulator made of metal.
Adjusted pressure stays constant despite pressure variations.
Standard overpressure blowoff valve.
Direct wall fixing or with distance.
Metal container with 360° viewing window.
Including pressure gauge.
Adjusted pressure stays constant despite pressure variations.
Standard overpressure blowoff valve.
Direct wall fixing or with distance.
Metal container with 360° viewing window.
Including pressure gauge.
| Series: | Newdeal |
| Connection: | Female thread G 1/4" |
| max. inlet pressure: | 18 |
| Filterfeinheit in µm: | 20 |
| Flow rate in l/min: | 260 |
| Shielding: | Technopolymer |
| Shielding plate: | Technopolymer |
| Container: | Aluminium |
| Seals: | NBR |
| Dome: | Technopolymer |
| Adjustment spring: | Steel |
| Adjustment knob: | Technopolymer |
| Adjusting nut: | Brass Ms58 |
| Adjusting screw: | Brass Ms58 |
| Filter element: | HDPE |
| Inner container: | Transparent technopolymer |
| Body: | Zamac |
| Piston: | Technopolymer |
| Lip seal: | NBR |
| Ring nut: | Technopolymer |
| Bar: | Brass Ms58 |
| Plug: | Technopolymer |
| Valve spring: | Steel |
| Valve part: | Vulcanized with NBR |
| Centrifuge: | Technopolymer |
| Weight in kg: | 0,379 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
