360° viewing glass.
Drain with manual condensate discharge and automatic discharge at zero pressure.
Additional ports for pressure gauges, pressure switches or for use as additional air take-off.
Drain with manual condensate discharge and automatic discharge at zero pressure.
Additional ports for pressure gauges, pressure switches or for use as additional air take-off.
| Series: | Syntesi |
| Connection: | Female thread G 1/2" |
| max. inlet pressure: | 13 |
| Filterfeinheit in µm: | 20 |
| Flow rate in l/min: | 5200 |
| Shielding plate: | Technopolymer |
| Seals: | NBR O-Ring |
| Input and output socket: | Brass Ms58 or aluminum, anodized |
| Filter element: | HDPE sintered |
| Filter case: | Technopolymer |
| Transparent container: | Technopolymer |
| Board: | Technopolymer |
| Centrifuge: | Technopolymer |
| Weight in kg: | 0,443 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
