• Minimum load loss as the flow rate varies.
• All-round condensate level viewing.
• Manual condensate discharge and automatic discharge at zero pressure.
• All-round condensate level viewing.
• Manual condensate discharge and automatic discharge at zero pressure.
| Series: | Bit |
| Connection: | Female thread G 1/4" |
| max. inlet pressure: | 13 |
| Mounting position: | Vertical |
| Installation: | M4 by means of the bracket provided |
| Filterfeinheit in µm: | 20 |
| Flow rate in l/min: | 1200 |
| Shielding: | Technopolymer |
| Container: | Transparent technopolymer |
| Seals: | NBR |
| Filter element: | HDPE |
| Body: | Technopolymer with threaded sleeve brass Ms58 |
| Centrifuge: | Technopolymer |
| Weight in kg: | 0,04 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
