For installation in transfer lines, machine tools and robot stations
Stainless steel housings
Stainless steel spindles
Floating bearings
High speeds for excellent processing quality
Maintenance-friendly
High true-running accuracy for long tool lives
With centrifugal governer All data related to 6.3 bar working pressure.
Stainless steel housings
Stainless steel spindles
Floating bearings
High speeds for excellent processing quality
Maintenance-friendly
High true-running accuracy for long tool lives
With centrifugal governer All data related to 6.3 bar working pressure.
| Idling speed rpm: | 100000 |
| Collet in mm: | 3 |
| Power in kW: | 0,1 |
| Direction of rotation: | Rotating clockwise |
| Exhaust Air: | to rear |
| Carbide burrs up to max. diam.: | 3 |
| Mounted points up to max. diam.: | 5 |
| Noise level in dB(A): | 69 |
| Air consumption in l/s: | 3,5 |
| Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen: | 6 \ 8 |
| Item number: | 29939577 |
| Weight in kg: | 0,26 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
Available downloads:
3D Modell
