Product information "ESR 84-4700 AX25 WS Air grinding spindle"

  • Use of non-lubricated air motors for low wear and long life time


All data related to 6.3 bar working pressure.
Exhaust Air: to front
Compliance force range in N: 25 - 1000
Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen: 14 \ 12
Item number: 60051305
Axial compliance in mm: 25
Radial deflection: -
Direction of rotation: Rotating clockwise
Air supply: lubricated
ER collet in mm: 6
Noise level in dB(A): 88
Weight in kg: 6,9
Idling speed rpm: 4700
Power in kW: 840
Air consumption in l/s: 18,5
Accessories supplied: Wrench
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
