Product information "ESR 551 Air grinding spindle"

  • High true-running accuracy for long endurance run times
  • High revolution speed for excellent surface finishing
  • The force of compliance can be set and adjusted precisely by using a precision pressure regulator


All data related to 6.3 bar working pressure.
Exhaust Air: to front
Fully variable force of compliance in N: 3 - 12
Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen: 2,7 \ 4
Item number: 60007395
Radial deflection: +/- 4°
Direction of rotation: Rotating clockwise
Air supply: lubricated
Noise level in dB(A): 78
Weight in kg: 0,57
Idling speed rpm: 55000
Power in kW: 100
Air consumption in l/s: 2,3
Accessories supplied: Wrench
ZG collet in mm: 3
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.


Skip product gallery

Zubehör

Spannzange M5
Collet 2,0 mm
Collet M5, clamping range ø 2,0 mm

€47.84
Spannzange M5
Collet 3,0 mm
Collet M5, clamping range ø 3,0 mm

€37.37
approx. 22 workdays
Spannzange M5
Collet 1,0 mm
Collet M5, clamping range ø 1,0 mm

€42.36
Spannzange M5
Collet 3/32"
Collet M5, clamping range ø 3/32"

€49.27
Spannzange M5
Collet 1/8"
Collet M5, clamping range ø 1/8"

€44.15
