- Use of non-lubricated air motors for low wear and long life time
All data related to 6.3 bar working pressure.
| Idling speed rpm: | 5000 |
| Air supply: | lubricated |
| Power in kW: | 380 |
| Radial deflection: | +/- 4° |
| Direction of rotation: | Rotating clockwise |
| Exhaust Air: | to front |
| ER collet in mm: | 6 |
| Compliance force range in N: | 10 - 150 |
| Noise level in dB(A): | 80 |
| Air consumption in l/s: | 8,3 |
| Accessories supplied: | Wrench |
| Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen: | 12 \ 14 |
| Item number: | 60051675 |
| Weight in kg: | 4,75 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
Available downloads:
3D Modell
