- Large revolution speed and power ranges for different deburring tasks
- Easy to mount horizontally or vertically onto a tool stand due to cuboid housing
- Easy to mount to a robot arm by thread connection
- Highest true running accuracy, load capability and best deburring results due to paired ball bearings
All data related to 6.3 bar working pressure.
| Idling speed rpm: | 28000 |
| Air supply: | lubricated |
| Power in kW: | 0.38 |
| Radial deflection: | +/- 4° |
| Direction of rotation: | Rotating clockwise |
| Exhaust Air: | to front |
| ER collet in mm: | 6 |
| Fully variable force of compliance in N: | 10 - 55 |
| Force of compliance max.* in N: | 200 |
| Noise level in dB(A): | 80 |
| Air consumption in l/s: | 11,5 |
| Accessories supplied: | Wrench |
| Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen: | 6 \ 8 |
| Item number: | 60019995 |
| Weight in kg: | 1,9 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
