ESR 170 Air grinding spindle

15.000 min⁻¹, 800 Watt, for most powerful deburring tasks

Price on request

Available in 8 days, transport time 1-2 working days

Large revolution speed and power ranges for different deburring tasks
Easy to mount horizontally or vertically onto a tool stand due to cuboid housing
Easy to mount to a robot arm by thread connection
Highest true running accuracy, load capability and best deburring results due to paired ball bearings

All data related to 6.3 bar working pressure.

Exhaust Air:	to front
Force of compliance max.* in N:	200
Fully variable force of compliance in N:	25 - 110
Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen:	6 \ 8
Item number:	60032405
Radial deflection:	+/- 4°
Direction of rotation:	Rotating clockwise
Air supply:	lubricated
ER collet in mm:	8
Noise level in dB(A):	82
Weight in kg:	5,15
Idling speed rpm:	15000
Power in kW:	800
Air consumption in l/s:	15
Accessories supplied:	Wrench

All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
