ESR 1000 X3 Air grinding spindle

100.000 min-1, 100 Watt, non-lubricated use, floating support
Price on request

Delivery time on request

Call for price
Call for price
Please enter these characters in the following text field.

Fields with * are required
High true-running accuracy for long endurance run times High revolution speed for... more
Product information "ESR 1000 X3 Air grinding spindle"
  • High true-running accuracy for long endurance run times
  • High revolution speed for excellent surface finishing
  • For non-lubricated use, practically wearless, with floating spindle support
  • Easy to service turbine motor
  • Ideal for plastics and other materials which require non-lubricated and clean air
  • The force of compliance can be set and adjusted manually
All data related to 6.3 bar working pressure.
Idling speed rpm: 100000
Air supply: Non-lubricated
Power in kW: 0,1
Radial deflection: +/- 4°
Direction of rotation: Rotating clockwise
Exhaust Air: to front
ZG collet in mm: 3
Fully variable force of compliance in N: 3 - 25
Noise level in dB(A): 70
Air consumption in l/s: 5,3
Accessories supplied: Wrench
Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen: 2,7 \ 4
Item number: 60053335
Weight in kg: 0,82

All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
