- For installation in transfer lines, machine tools and robot stations
- Stainless steel housings
- Stainless steel spindles
- With collet chuck or precision collet chuck
- High true-running accuracy
- Paired bearings for longer tool life time and better running properties
- Optional with rotating splashguard to prevent penetration of dust, water or chips
| Idling speed rpm: | 24000 |
| Power in kW: | 0,32 |
| Direction of rotation: | Rotating clockwise |
| Exhaust Air: | to rear |
| ER collet in mm: | 6 |
| Carbide burrs up to max. diam.: | 12 |
| Mounted points up to max. diam.: | 25 |
| Noise level in dB(A): | 78 |
| Air consumption in l/s: | 12,5 |
| Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen: | 10 \ 12 |
| Item number: | 60012337 |
| Weight in kg: | 0,74 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
Available downloads:
3D Modell
