- For installation in transfer lines, machine tools and robot stations
- Stainless steel housings
- Stainless steel spindles
- Ideal for countersinking
- Collets up to 10 mm
| Idling speed rpm: | 520 |
| Power in kW: | 0,38 |
| Senkbereich in mm: | 5 - 30 |
| Anlauf: | external |
| Direction of rotation: | Rotating clockwise |
| Exhaust Air: | to rear |
| ER collet in mm: | 10 |
| Noise level in dB(A): | 77 |
| Air consumption in l/s: | 8,5 |
| Anschluss Zuluftschlauch (Blitz) ø mm, innen \ außen: | 10 \ 12 |
| Item number: | 60001367 |
| Weight in kg: | 1,4 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
Available downloads:
3D Modell
