Allows air to pass in one direction while blocking flow in the other direction. Integrated function for accurate opening pressure adjustment. Nickel-plated brass construction for resistance to severe environments.
| Material seal: | FKM |
| Material spring: | Stainless steel |
| Material body: | Brass nickel plated chemical fda brass |
| Material seat seal: | NBR |
| Material stem: | Brass |
| Material union nut: | Brass |
| min. temperature in °C: | -20 |
| max. temperature in °C: | 80 |
| Material: | Brass nickel plated chemical fda brass |
| RoHS compliant: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
