miniature ball valve, 3/2, with vent and push-in connection:
- Opening/closing of pneumatic circuits
- Compact and light weight, suitable for all types of installations thanks to the 3 types of mounting available.
- Opening/closing of pneumatic circuits
- Compact and light weight, suitable for all types of installations thanks to the 3 types of mounting available.
| Material seal: | NBR |
| Material body: | Engineered polymer |
| Material lever: | Engineered polymer |
| Material stem: | Brass |
| Material plug sockets O-ring: | NBR |
| Material toothed washer: | Stainless steel |
| min. temperature in °C: | -20 |
| max. temperature in °C: | 80 |
| Material: | Engineered polymer |
| RoHS compliant: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
