Blocking fitting with push-in connection and precoated thread:
- Fully orientable in order to facilitate system design and connection
- Body in treated brass
- Optimum flow capactity in small spaces
- Fully orientable in order to facilitate system design and connection
- excellent resistance to aggressive environments (saline atmosphere and sparks).
- Fully orientable in order to facilitate system design and connection
- Body in treated brass
- Optimum flow capactity in small spaces
- Fully orientable in order to facilitate system design and connection
- excellent resistance to aggressive environments (saline atmosphere and sparks).
| Seal coating: | PTFE |
| Material seal: | NBR |
| Material body: | Brass nickel plated |
| Material threaded fitting: | Brass nickel plated |
| Material diaphragm: | NBR |
| Material toothed washer: | Stainless steel |
| min. temperature in °C: | -20 |
| max. temperature in °C: | 70 |
| Material: | Brass nickel plated |
| RoHS compliant: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
