throttle valve, threaded, made of stainless steel, uni-directional:
- for line installation
- Large adjustment screw and lock nut guaranteeing stability of adjustment
- Throtteling of air supply and exhaust, no non-return function.
- ideally suited for aggressive atmospheres or environments submitted to severe chemical or mechanical constraints
- for line installation
- Large adjustment screw and lock nut guaranteeing stability of adjustment
- Throtteling of air supply and exhaust, no non-return function.
- ideally suited for aggressive atmospheres or environments submitted to severe chemical or mechanical constraints
| Flow rate in l/min: | 2300 |
| Material seal: | FKM |
| Material adjusting spindle: | Stainless steel 316l |
| Material body: | Stainless steel 316l |
| Material lever: | Stainless steel 316l |
| Material stem: | Stainless steel 316l |
| min. temperature in °C: | -15 |
| max. temperature in °C: | 120 |
| Material: | Stainless steel 316l |
| RoHS compliant: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
