Non-return throttle valve, threaded, made of plastic, for line installation: - with push-in connection, panel mountable, uni-directional - two versions for micro-adjustments available (7776 04 00 and 7776 06 00) - prevention against unwanted adjustment with a lock nut - small and lightweight for easy installation - versatile
Weight in kg:
0,069
Maximum working pressure in bar:
10
max. temperature in °C:
70
RoHS compliant:
Yes
Material seal:
NBR
Material adjusting spindle:
Brass nickel plated
Material body:
Engineered polymer
Material locknut:
Brass nickel plated
Material stem:
Brass nickel plated
Material toothed washer:
Stainless steel
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
