Non-return throttle valve, threaded, made of metal:
- with universal brass compression fitting, R-thread
- banjo with recessed screw for throtteling exhaust air
- lock nut guaranteeing stability of adjustment
- reliable, precise and progressive adjustment
- strong construction for improved longevity
- treated brass body extremely resistant to external aggressions - temperature, sparking, corrosion
- with universal brass compression fitting, R-thread
- banjo with recessed screw for throtteling exhaust air
- lock nut guaranteeing stability of adjustment
- reliable, precise and progressive adjustment
- strong construction for improved longevity
- treated brass body extremely resistant to external aggressions - temperature, sparking, corrosion
| Maximum working pressure in bar: | 10 |
| Material seal ring: | Galvanized steel with NBR seal |
| Material seal: | NBR |
| Material adjusting spindle: | Brass nickel plated |
| Material body: | Brass |
| Material gripping ring: | Brass |
| Material locknut: | Brass nickel plated |
| Material union nut: | Brass |
| max. temperature in °C: | 70 |
| RoHS compliant: | Yes |
| Weight in kg: | 0,129 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
