Legris Pressure regulators: Stabilize the pressure at a given value. Very compact, they can be assembled downstream or upstream of the distributor.Mounted in series on a manifold, these fittings control the supply required for each piece of equipment. Model with instant connection and BSP parallel thread.
| Material seal: | NBR |
| Material adjusting spindle: | Brass nickel plated |
| Material body: | Engineered polymer |
| Material body 2: | Brass nickel plated |
| Material toothed washer: | Stainless steel |
| min. temperature in °C: | -10 |
| max. temperature in °C: | 70 |
| Material: | Engineered polymer |
| RoHS compliant: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
Available downloads:
