Non-return throttle valve, threaded, made of metal:
- with push-in connection and G-thread
- external screw for throtteling exhaust air
- lock nut guaranteeing stability of adjustment
- reliable, precise and progressive adjustment
- strong construction for improved longevity
- treated brass body extremely resistant to external aggressions - temperature, sparking, corrosion
- with push-in connection and G-thread
- external screw for throtteling exhaust air
- lock nut guaranteeing stability of adjustment
- reliable, precise and progressive adjustment
- strong construction for improved longevity
- treated brass body extremely resistant to external aggressions - temperature, sparking, corrosion
| Material seal: | NBR |
| Material adjusting spindle: | Brass nickel plated |
| Material body: | Brass nickel plated |
| Material locknut: | Brass nickel plated |
| Material toothed washer: | Stainless steel |
| max. temperature in °C: | 70 |
| Material: | Brass nickel plated |
| RoHS compliant: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
