regulators for bulkhead mounting made of anodized aluminium:
- in-line model
- lock nut to prevent unwanted adjustment
- panel mounted
- ease of installation
Flow regulators - metal version, adapted for use in severe environments.
- in-line model
- lock nut to prevent unwanted adjustment
- panel mounted
- ease of installation
Flow regulators - metal version, adapted for use in severe environments.
| Maximum working pressure in bar: | 10 |
| Material seal: | NBR |
| Material adjusting spindle: | Brass |
| Material body: | Aluminium treated |
| Material locknut: | Brass |
| Material stem: | Brass |
| min. temperature in °C: | -20 |
| max. temperature in °C: | 80 |
| RoHS compliant: | Yes |
| Weight in kg: | 0,022 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
