Straight non-return throttle valve, threaded, made of plastic:
- push-in connection
- adjustment with a protective cover
- lock nut guaranteeing stability of adjustment
- Ideally suitable for reduced spaces
- push-in connection
- adjustment with a protective cover
- lock nut guaranteeing stability of adjustment
- Ideally suitable for reduced spaces
| Maximum working pressure in bar: | 10 |
| Material seal: | NBR |
| Material adjusting spindle: | Brass nickel plated |
| Material body: | Engineered polymer |
| Material threaded fitting: | Brass nickel plated |
| Material locknut: | Brass nickel plated |
| Material toothed washer: | Stainless steel |
| max. temperature in °C: | 70 |
| RoHS compliant: | Yes |
| Weight in kg: | 0,11 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
